MK4 Supra Body Connector Kits — 16P + 20P + 38P (JZA80)
OEM P/N 90980-11562 · 90980-11469 · 90980-11555
SKU: SVK-MK4-CHAS-SET · Fits 1993–2002 Toyota Supra MKIV · 2JZ-GTE / 2JZ-GE
All three MK4 (MKIV) Toyota Supra JZA80 footwell body connector kits together — the white 16-pin (OEM 90980-11562), gray 20-pin (90980-11469) and orange 38-pin (90980-11555). These are the three connectors joining the engine harness to the body harness. Every kit includes the connector housing plus terminals for all positions, and the factory weather seals where the connector came with them.
Saves $20 versus buying the three kits individually — the best value for a full chassis harness restoration or a 2JZ swap that keeps a factory-quality disconnect point.
- Includes all three main chassis harness connectors
- 16-pin, 20-pin, and 38-pin — all OEM Toyota compatible
- Save compared to purchasing connectors individually
- Ideal for complete chassis harness builds or full restores
- 1-year warranty on workmanship
Specifications
| OEM Part Numbers | 90980-11562 (16P), 90980-11469 (20P), 90980-11555 (38P) |
|---|---|
| SVK Part Number | SVK-MK4-CHAS-SET |
| Contents | White 16-pin, gray 20-pin and orange 38-pin connector kits |
| Chassis | Toyota Supra MK4 / MKIV (JZA80) |
| Model Years | 1993–2002 |
| Engines | 2JZ-GTE (turbo) and 2JZ-GE (NA) |
| Application | Footwell body connectors — engine harness to body harness |
| Kit Contents | Housings and terminals for every position; factory seals where applicable |
| Type | OEM Toyota compatible |
| Warranty | 1-year workmanship warranty |
